| Image Sensor |
1/3" 520K SONY or Sharp CCD SENSOR |
| H. Resolution |
NTSC - 700TVL / PAL - 720TVL |
| Scanning System |
NTSC : 1020(H) X 507(V) / PAL : 1020(H) X 520(V) |
| Min. Illumination |
0.05Lux (IR LED Off) |
| Video output Level |
1.0Vp-p (75ohms, Composite) |
| S/N Ratio |
More than 48dB (AGC Off) |
| Gamma |
r = 0.45 |
| White Balanc |
Auto White Balance |
| Gain Control |
4dB - 32dB - Auto |
| Visibility Range |
Outdoor 10M / Indoor20M |
| IR LED |
10 IR LEDs (850nm, 30Degree,Visiable,50mA , 5ǿ) |
| MIRROR |
ON/OFF(Magnetic) |
| Operating Humidity |
- 20℃ - +50℃ (10% - 95% RH) |
| Lens |
STD Lens : f = 3.6mm Lens |
| MTBF |
80,000 Hour |
| AUDIO |
OPTION |
| HEATER |
OPTION |
| Power Supply Range |
DC 12V 10% |
| Power Source |
MAX. DC12V 150mA |
| Dimensions |
41(W) x41(H) x43(D)mm |
| Net Weight |
300g |
